ML-x-45

LED machine lights, IP68, corner mounting

The machine light allows for compact dimensions easy mechanical integration into machines without significantly restricting the space available. A simple electrical installation will be  carried over directly to 24 V DC M12 Connector systems.

With a robust aluminum housing and a weatherproof, UV resistant and crystal clear polyurethane casting, the LED light from the environment and numerous chemicals such as alkalis, acids and oils, is protected.

The highly efficient LEDs have a beam angle of 100° and produce a homogeneous, flicker-free light.

The ML-Series are available in 5 sizes and two built-in M6 nuts are provided for corner mounting.

Product Line

Variants of the product series


Item Num. Type Picture Power Tension Dimensions Connection Data sheet CE Compliant 3D Data Price (netto) Inquiry
10204 ML-6-45 M12
GTIN / EAN: 4262388140020
6W 24V DC 200 x 40 x 40 [mm] M12 Connector 102,00 EUR
10276 ML-6-45 LC
GTIN / EAN: 4262388140471
6W 24V DC 200 x 40 x 40 [mm] Cable 5m PUR/PVC 102,00 EUR
10205 ML-12-45 M12
GTIN / EAN: 4262388140037
12W 24V DC 370 x 40 x 40 [mm] M12 Connector 174,00 EUR
10263 ML-12-45 LC
GTIN / EAN: 4262388140365
12W 24V DC 370 x 40 x 40 [mm] Cable 5m PUR/PVC 174,00 EUR
10214 ML-18-45 M12
GTIN / EAN: 4262388140099
18W 24V DC 540 x 40 x 40 [mm] M12 Connector 238,00 EUR
10266 ML-18-45 LC
GTIN / EAN: 4262388140396
18W 24V DC 540 x 40 x 40 [mm] Cable 5m PUR/PVC 238,00 EUR
10250 ML-24-45 M12
GTIN / EAN: 4262388140297
24W 24V DC 540 x 40 x 40 [mm] M12 Connector 259,00 EUR
10270 ML-24-45 LC
GTIN / EAN: 4262388140426
24W 24V DC 540 x 40 x 40 [mm] Cable 5m PUR/PVC 259,00 EUR
10292 ML-36-45 M12
GTIN / EAN: 4262388140549
36W 24V DC 800 x 40 x 40 [mm] M12 Connector 305,00 EUR
10498 ML-36-45 LC
GTIN / EAN: 4262388140624
36W 24V DC 800 x 40 x 40 [mm] Cable 5m PUR/PVC 305,00 EUR
